Launch X-431 IMMO Pad All-In-One Car Diagnostic
Launch X-431 IMMO Pad All-In-One Car Diagnostic Key Programming Tool
Description
Launch X-431 IMMO PAD is based on the Android 7.1 platform and is equipped with an octa-core 2.0GHz processor, 4GB of memory and 64GB of storage. Its 10.1-inch full-fitting sunlight-readable Gorilla Glass screen boasts a vibrant 1920 x 1200 resolution. The tablet is IP65-rated water- and dust-resistant, with a dual-band Wi-Fi architecture providing a more reliable tool-to-VCI connection. The upgraded all-in-one Smartlink VCI supports CAN, CANFD, DoIP, J2534, D-PDU, RP1210 and Smartlink remote service, which enables the capability of ECU coding and programming that are required usually after immobilizer replacement.The upgraded Launch X-Prog 3 enables reading/writing EEPROM, on-board MCU and BMW CAS4+/FEM chips, Mercedes-Benz infrared keys, generating special keys, reading BMW engine ISN code.
Launch X431 IMMO PAD Highlights:
1. Supports VW/AUDI MQB platform engine ECU replacement or cloning (Read engine ECU data directly from the key).
2. Supports VW/AUDI MQB platform gearbox ECU replacement or cloning.
3. Supports ECU replacement for fifth-generation Audi (0AW/0B5) gearboxs.
4. Supports reading, writing & cloning of the ECU for fourth-generation VW UDS engines.
5. Supports BMW E chassis 8HP gearbox ECU program wiping.
6. Support Mercedes(Engine, Gearbox, EIS) and BMW(Gearbox) ECU anti-theft data erase.
7. Supports 170+ Bosch, 10+ Siemens engine ECU and 18+ gearbox ECU BENCH mode clone.
- Bosch engine ECU: ME17，MED17，EDC17，MEVD17, etc.
- Siemens engine ECU: BMW(MSV90, MSD87, MSD85,MSD81, MSD80), Mercedes(SIM271DE2.0,SIM271KE2.0), VW/Audi(SIMOS8.6x,SIMOS8.5x,SIMOS8.4x), etc.
- Gearbox ECU: DQ200-MQB, DQ250XX, DL501 Gen1,VL381,VGS2- FCVT,VGS-FDCT,DQ400E,DL501 Gen2,DL382-7F,VGS2-FDCT,9G_Tronic,DQ380,DQ381, DQ500,AL551,AL450,AL552,AL951,8HPXX, etc.
Launch X431 IMMO PAD Functions:
Intelligent Diagnostic Function:1. All systems OE-Level diagnostics for over 110 vehicle models.
2. Exceptional full functionality includes comprehensive OBD II diagnostics, bi-directional control, ECU coding & programming, etc.
3. Support CAN/CANFD/DoIP communication protocols and J2534/D-PDU/RP1210 communication standards.
4. Exclusive Smartlink remote diagnosis.
5. 25 advanced service functions.
6. Pre-scan and post-scan diagnostic report.
7. Expand diagnostic coverage via “Mall”.
8. Optional ADAS calibration function with the X-431 ADAS calibration tools.
9. Optional TPMS function with X-431 TSGUN.10. Two years free updates.
Key Programming Function:
1. Supports key matching/copying, anti-theft IC reading & writing, and ECU reading & writing, etc.
2. Anti-theft modules replacement:Support anti-theft modules replacement of BMW, Mercedes-Benz, VW/Audi, Honda, Nissan, Hyundai, Kia, BYD, Changan, Wuling Baojun, GAC, SAIC Maxus, Great Wall Motor, Chery Car, Dongfeng Fengxing, JAC Passenger Car, etc
3. Anti-theft password reading:Supports the anti-theft password reading of Peugeot Citroen, GM, Nissan, Hyundai, Kia, Chery Cars, Dongfeng Fengxing, JAC Passenger Cars, etc.
4. Key Matching: Support key matching of Ford, GM, Mercedes-Benz, BMW, VW/Audi, Porsche, Peugeot Citroen, Land Rover Jaguar, Honda, Toyota, Nissan, Hyundai, Kia, BYD, Changan Automobile, Wuling Baojun, Great Wall Motors, Chery Cars, JAC Passenger Cars, etcLaunch IMMO PRO and IMMO Pad Introduction
x431 programing coding initialization
Product Insight: Launch IMMO PAD and X-PROG3
X-431 IMMO PAD | Unbox the X-431 IMMO PAD | LAUNCH
Launch "IMMO PROG" Module Introduction Supported by IMMO Pro/Pad and X-PROG 3
Launch X431 X-PROG 3 Introduction
VW & Audi
Audi A5 replace used Gearbox with LAUNCH X431 X-PROG3 Clone function
Mercedes Benz
LAUNCH X431 IMMO PAD Programming a new key to W204 with LAUNCH X431 IMMO PAD
Mercedes-Benz W205 C350e Airmatic level calibration by LAUNCH X431 IMMO PAD
Mercedes Benz 2004-2014 IR Key Remote Fob Add Programming by Launch IMMO Pro
LAUNCH X431 PAD III - Program & coding Mercedes TCU 722 9 GLK300
Other
HONDA CITY 2013 ADD NEW KEY with LAUNCH X431 IMMO PAD
Toyota Key Adding by Launch Tools
Hyundai and Kia Key/Fob Learn/Programming via Launch Scanner
BMW
BMW 530e (G30) ZBE/CON encoding with LAUNCH X431 IMMO PAD
BMW CAS3/CAS3+ Key Adding via Launch IMMO Pro/Pad or X-PROG 3
BMW CAS3/CAS3+ Smart/Remote Key/Fob All Key Lost Programming via Launch IMMO Pro/Pad or X-PROG 3
BMW DME MSV90 ECU CLONE with LAUNCH X431 IMMO PAD
EEPROM
X-431 IMMO | Bosch/Simens Engine ECU EEPROM Data Backup And Restore | LAUNCH
EEPROM Read and Write by Launch IMMO Pad/Pro or X-PROG 3
PORSCHE
The “procedure” function on Porsche for engine computer clone “SD17"
Launch X-431 IMMO PAD Tablet Specification:
Processor
2.0GHz, Octa-Core
Operation System
Android 7.1
Memory
4GB
Storage
64GB
Battery
9360mAh
Display
10.1'', 1920*1200
Camera
Front 8MP, Rear 13MP
Protection
IP65
WIFI
2.4GHz/5GHz
Interface
TYPE A *1 & TYPE C*1
Working Temperature
0~50℃
Dimension
320 x 211 x 46mm
Smartlink C VCI Specification:
Display
3.97“ single-touch screen, 320*480
Memory
256MB
Storage
8GB
Remote Communication
WIFI / Ethernet
Working Voltage
DC 9V – 36V
USB
Type B USB2.0
Power Consumption
<6W
Work Temperature
0~50℃
Dimension
204 x 110 x 45mm
Launch X-PROG 3 Specification:
Interface DB26, DB15 Input Voltage DC12V Input Current 500mA Working Temperature 0~50℃ Storage Temperature -20~70℃ Vehicle Key Slot
To place car key for RF defection
DB26
Used to connect to each anti-theft cables
Infrared slot for Benz key
Used to place the Mercedes-Benz infrared key to perform the key matching function
Key IC hole
Used to place the key chip to perform the key matching function
Status Indicator
Power supply indicator lamp
DIY Slot
Used to connect the anti-theft ECU pin through the cable to read and write data
Locker
To tighten loose EEPROM board
DC 12V
Used to connect to the DC12 power supply
DB15
To connect with vehicle’s DLC
EEPROM Slot
To insert EEPROM board
44.8 * 44.0 * 39.6 cm
13.9kg
